Specifications
Type: auto reverse, double compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.76 cm/s
Heads: 1 x playback, 1 x record/playback, 1 x erase
Motor: DC servo
Tape Type: type I, CrO2, Metal
Noise Reduction: B, C
Headroom Extension: HX Pro
Frequency Response: 30Hz to 18kHz (Metal tape)
Signal to Noise Ratio: 79dB (dolby C)
Wow and Flutter: 0.08%
Total Harmonic Distortion: 3%
Input: 87mV (line), 0.35mV (mic)
Output: 0.55V (line)
Dimensions: 435 x 127 x 262mm
Weight: 4.7kg
Finish: black
Year: 1989
Repair
Belts, Idler Tires, Pinch Rollers changed
Cleaned and Tested
JA 366
