Pioneer SX-1250 LOCAL PICKUP ONLY
Just Audio HiFiPioneer SX-1250 LOCAL PICKUP ONLY
Pioneer SX-1250

Specifications:

Tuning range: FM, MW

Power output: 160 watts per channel into 8Ω (stereo)

Frequency response: 10Hz to 50kHz

Total harmonic distortion: 0.1%

Damping factor: 30

Input sensitivity: 6.5mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)

Signal to noise ratio: 75dB (MM), 90dB (line)

Output: 150mV (line), 30mV (DIN), 1V (Pre out)

Speaker load impedance: 4Ω (minimum)

Dimensions: 556 x 186.5 x 464.5mm

Weight: 29.2kg

Year: 1976

Repair:

LED Upgrade

Relay Changed

Unit Recapped

Power Stabilizer Board /EQ Board/ Filter Amp/ Control Amp/ Flat Amp/ Tuner Transistors Changed

Some Power Amp Transistors Changed

Pots/Switches Cleaned

Bias Adjusted

Cleaned and Tested
