Specifications
Tuning range: FM, MW
Power output: 45 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.3%
Damping factor: 45
Input sensitivity: 1.8mV (MM), 180mV (line)
Signal to noise ratio: 80dB (line)
Channel separation: 35dB (line)
Speaker load impedance: 4Ω to 16Ω
Dimensions: 17-21/64 x 5-25/64 x 14 inches
Weight: 34.5lbs
Year: 1971
Repair:
LED Upgrade
Power Amp Recapped
Power Supply Recapped
Relay Changed
Bias Adjusted
Pots/Switches Cleaned
Cleaned and Tested
